Power control (PWR)
Figure 5.
Power on reset/power down reset waveform
RM0008
V DD /V DDA
POR
40 mV
hysteresis
PDR
Temporization
t RSTTEMPO
Reset
4.2.2
Programmable voltage detector (PVD)
You can use the PVD to monitor the V DD /V DDA power supply by comparing it to a threshold
selected by the PLS[2:0] bits in the Power control register (PWR_CR) .
The PVD is enabled by setting the PVDE bit.
A PVDO flag is available, in the Power control/status register (PWR_CSR) , to indicate if
V DD /V DDA is higher or lower than the PVD threshold. This event is internally connected to
the EXTI line16 and can generate an interrupt if enabled through the EXTI registers. The
PVD output interrupt can be generated when V DD /V DDA drops below the PVD threshold
and/or when V DD /V DDA rises above the PVD threshold depending on EXTI line16
rising/falling edge configuration. As an example the service routine could perform
emergency shutdown tasks.
Figure 6.
PVD thresholds
V DD /V DDA
PVD output
PVD threshold
100 mV
hysteresis
56/995
Doc ID 13902 Rev 9
